| Type of Product | Multifunction Process Calibrator |
| Accuracy | Resistance: ±0.5% |
| Operating Temperature | -10°C to 55°C |
| Storage Temperature | -20°C to 70°C |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Multifunction Process Calibrator |
Accuracy |
Resistance: ±0.5% |
Operating Temperature |
-10°C to 55°C |
Storage Temperature |
-20°C to 70°C |
Package Contains |
1 x Main Unit, Signal Generator x 1, Users Manual x 1, Signal Cable x 3, USB Cable x 1, Charging Plug x 1, Tool Kit x 1, Test Leads (Red and Black) x 1 |
Dimension |
115 x 70 x 26 mm |
Model No |
333P+ |
Resistance |
20 to 400 Ω |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
MECO INSTRUMENTS |
Units |
mA / mV / V / °C |
Function |
Cold End and Programming Function, Range Conversion Function |
Humidity |
20 to 80% RH |
Drive Current |
24 mA |
Voltage Signal |
0 - 30 V, 0 - 25 mV, 0 - 100 mV DC |
Jaw Opening |
For Cable / Conductor upto 43 mm / Busbar upto 65 mm x 16 mm |
Current Signal |
0 - 25 mA, 4 - 20 mA DC |
Auto Shutoff |
Yes |
Sensor Type |
PT100 Thermistor |
