| Type of Product | Handheld Oscilloscope |
| Bandwidth | 40 MHz |
| Vertical Resolution | 8 bits |
| Channel | 2 Channel |
Type of Product |
Handheld Oscilloscope |
Bandwidth |
40 MHz |
Vertical Resolution |
8 bits |
Channel |
2 Channel |
Display |
3.5 inch (88.9 mm) LCD |
Model No |
OM-40 |
Input Impedance |
1 MΩ±2%, in parallel with 16pF±10pF |
Vertical Sensitivity |
10mV/div - 10V/div |
Input Coupling |
DC, AC and Ground |
Country of Origin |
India |
Record Length |
8K |
Name of Manufacturer/Packer/Importer |
Rameshtha Enterprises |
Waveform Refresh Rate |
10,000 wfrms/s |
Maximum Input Voltage |
400V (DC+AC, PK-PK, 1M input impedance) (10:1 probe attenuation) |
Horizontal Scale |
5ns/div - 1000s/div, step by 1-2-5 |
Acquisition Model |
Normal, Peak detect |
