Ships within 30 days
Clamping Force
Clamping Stroke
View
View
View
View
| Weight | 200 g |
| Model No | 3106-18B |
| Type of Product | Low Profile Clamps |
| Country of Origin | India |
Weight |
200 g |
Model No |
3106-18B |
Type of Product |
Low Profile Clamps |
Country of Origin |
India |
Type |
Blunt Edge |
Material |
Steel SKD12 |
Series |
3106 Series |
Finish Type |
Black Oxide Finish |
Name of Manufacturer/Packer/Importer |
Steel-Smith |
Dimension M |
M12x1.75-30L |
Dimension W |
38.1 mm |
Clamping Force |
50000 N |
Dimension W1 (mm) |
10 mm |
Dimension H |
9.5 mm |
Screw Torque |
145 N.m |
Dimension L1 |
38.1 mm |
Clamping Stroke |
1.9 N |
Hardness |
HRC45~48 |
