| Insulation Material | TFE |
| Conductor Material | Silver Plated Copper |
| Color | Transparent |
| Attenuation | 4.4 dB/10 m @ 100 mHz |
Insulation Material |
TFE |
Conductor Material |
Silver Plated Copper |
Color |
Transparent |
Attenuation |
4.4 dB/10 m @ 100 mHz |
Capacitance |
93.1 pF/m |
Series |
Alpha Essentials Coaxial Cable |
Type of Product |
Coaxial Cable |
Model No |
9178B CL005 |
Length |
30 m |
No. of Strands |
1 |
Shield |
Braid |
Sheath Material |
EFF |
Country of Origin |
Mexico |
Characteristic impedance (Ω) |
50 Ω |
Operating Temperature Range |
-20 to +60 °C |
Outer Diameter |
1.8 mm |
Maximum Operating Temperature |
+60°C |
Minimum Operating Temperature |
-20°C |
Strands |
0.3 mm |
Standard Met |
CE |
Voltage Rating |
750 V |
Coaxial Type |
RG178B/U |
Conductor Strand Type |
Solid |
Terminated/Unterminated |
Unterminated |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Core Strands |
1/0.3 mm |
