| Insulation Material | PTFE |
| Type | Stranded |
| Conductor Material | Silver Plated Copper Clad Steel |
| Color | Brown |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Insulation Material |
PTFE |
Type |
Stranded |
Conductor Material |
Silver Plated Copper Clad Steel |
Color |
Brown |
Attenuation |
96 dB at 1000 MHz |
Capacitance |
95 pF/m |
Type of Product |
Co-Axial Cable |
Model No |
9060641 |
No. of Strands |
7 |
Shield |
Silver Plated Copper Braid |
Sheath Material |
FEP |
Stranded Size |
0.18 mm |
Country of Origin |
United Kingdom |
Termination Type |
Unterminated |
Operating Temperature Range |
-70 to +200°C |
Velocity |
0.69499999999999995 |
Outer Diameter |
2.55 mm |
Maximum Operating Temperature |
+200°C |
Minimum Operating Temperature |
-70°C |
Strands |
7/0.18 |
Standard |
Euroclass Eca |
Coaxial Type |
RG316 |
Impedance (Ohms) |
50 Ω |
Name of Manufacturer/Packer/Importer |
RS Component |
