| Type of Product | Command Switch |
| Monotaro ID | 50052791 |
| Mounting Hole Diameter (Φmm) | 22 |
| Type | Control Type |
Type of Product |
Command Switch |
Monotaro ID |
50052791 |
Mounting Hole Diameter (Φmm) |
22 |
Type |
Control Type |
Protection Class |
IP65 (oil-proof type) |
Import Country |
Direct Import from Japan |
Model No |
AR22JCY-3G11CA |
Mechanical Durability |
1,000,000 times or more |
Electrical Durability |
500,000 times or more (at AC220V 6A), 1 million times or more (at AC220V 3A) |
Contact Configuration |
1A1B |
Storage Temperature |
-40 to 80℃ |
Withstand Voltage |
Between live part and ground / between different polarity live parts: 2500 VAC for 1 minute |
Short Circuit Protection Device |
Fuse 15A |
Return Function |
mixture |
Pollution Degree (Environment to Use) |
3 |
Mounting Dimensions (mm) |
Φ22.3/ Φ25.5 shared |
Terminal Screw |
M3.5 plus/minus screw with square washer (self-lifting type) |
Frame |
Rounded frame |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Number of Notches |
3 |
Insulation Resistance (MOhm) |
Between live part and ground / between different polarity live parts: 100 or more (at 500 VDC megger) |
Rated Insulation Voltage (V) |
AC/DC 600 |
Operation Ambient Temperature (°C) |
-20 to 70 (no freezing or condensation) |
Rated Impulse Withstand Voltage (kV) |
6 |
