| Type of Product | Command Switch |
| Monotaro ID | 49994856 |
| Mounting Hole Diameter (Φmm) | 16 |
| Type | Selector |
Type of Product |
Command Switch |
Monotaro ID |
49994856 |
Mounting Hole Diameter (Φmm) |
16 |
Type |
Selector |
Terminal Shape |
For solder and tab (# 110) |
Import Country |
Direct Import from Japan |
Model No |
AF16JS-2DC1F |
Mechanical Durability |
250,000 times or more |
Electrical Durability |
100,000 times or more (at AC220V 0.7A) |
Contact Configuration |
1C |
Storage Temperature |
-40 to +70℃ |
Withstand Voltage |
Between charging part and ground: AC2000V 1 minute, between opposite pole charging part: AC2000V 1 minute |
Short Circuit Protection Device |
gG 2A (IEC60269 fuse) |
Return Function |
Manual |
Pollution Degree (Environment to Use) |
3 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Number of Notches |
2 |
Insulation Resistance (MOhm) |
100 or more (at 500 VDC megger) |
Vibration Resistance |
Resonance test: Double amplitude 0.1 mm Frequency 10-55Hz / Constant vibration endurance test: Double amplitude 3.0 mm Frequency 16.7Hz |
Rated Insulation Voltage (V) |
AC/DC 250 |
Operation Ambient Temperature (°C) |
-10-+55 (no freezing or condensation) |
Notch Angle |
90° |
Rated Impulse Withstand Voltage (kV) |
2.5 |
