| Type of Product | Command Switch |
| Monotaro ID | 50043393 |
| Mounting Hole Diameter (Φmm) | 16 |
| Type | Selector |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Command Switch |
Monotaro ID |
50043393 |
Mounting Hole Diameter (Φmm) |
16 |
Type |
Selector |
Protection Class |
Operation unit (display unit) protection structure: IP65 (dust-resistant / jet-proof type) IEC 60529, IP65F (dust-resistant / jet-proof / oil-proof type) JIS C 0920 / terminal protection structure: IP2X (for quick connection) When socket AR6S690, connector socket AR6S691-C or charging part protection cover AR6Y261 is installed) |
Terminal Shape |
For solder and tab (# 110) |
Import Country |
Direct Import from Japan |
Model No |
AR16JT-2BC1B |
Mechanical Durability |
250,000 times or more |
Electrical Durability |
100,000 times or more (at AC220V 0.7A) |
Contact Configuration |
1C |
Storage Temperature |
-40 to 70℃ |
Withstand Voltage |
Between live part and ground / between different polarity live parts: 2000 VAC for 1 minute |
Short Circuit Protection Device |
gG 2A |
Return Function |
Manual |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Number of Notches |
2 |
Insulation Resistance (MOhm) |
100 or more (at 500 VDC megger) |
Rated Insulation Voltage (V) |
AC/DC 250 |
Operation Ambient Temperature (°C) |
-10 to 55 (no freezing or condensation) |
Standard |
AR16438 |
Notch Angle |
90° |
Rated Impulse Withstand Voltage (kV) |
2.5 |
Lens |
Left / right |
