| Type of Product | Command Switch |
| Monotaro ID | 50172412 |
| Shape | (Display section) Round protrusion type |
| Type | Indicator Light |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Command Switch |
Monotaro ID |
50172412 |
Shape |
(Display section) Round protrusion type |
Type |
Indicator Light |
Protection Class |
Operation unit (display unit) protection structure: IP65 (dust-resistant / jet-proof type) IEC 60529, IP65F (dust-resistant / jet-proof / oil-proof type) JIS C 0920 / terminal protection structure: IP2X (for quick connection) When socket AR6S690, connector socket AR6S691-C or charging part protection cover AR6Y261 is installed) |
Import Country |
Direct Import from Japan |
Model No |
DR16E0L-B3W |
Storage Temperature |
-40 to 70℃ |
Withstand Voltage |
Between live part and ground / between different polarity live parts: 2000 VAC for 1 minute |
Short Circuit Protection Device |
gG 2A |
Pollution Degree (Environment to Use) |
3 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Operation Mechanism |
Round shape |
Light Colour |
Orange |
Insulation Resistance (MOhm) |
100 or more (at 500 VDC megger) |
Vibration Resistance |
Resonance test: Double amplitude 1.0 mm Frequency 10-55Hz / Constant vibration endurance test: Double amplitude 3.0 mm Frequency 16.7Hz |
Rated Insulation Voltage (V) |
AC/DC 250 |
Operation Ambient Temperature (°C) |
-10 to 55 (no freezing or condensation) |
Rated Impulse Withstand Voltage (kV) |
2.5 |
Lamp Type |
LED |
Lamp Voltage (V) |
AC/DC 12 |
Method |
All voltage type |
Voltage |
AC/DC 12 V |
Lens Color |
Milky white |
