| Type of Product | Command Switch |
| Monotaro ID | 50026891 |
| Mounting Hole Diameter (Φmm) | 22.3 |
| Type | Standard Type |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Command Switch |
Monotaro ID |
50026891 |
Mounting Hole Diameter (Φmm) |
22.3 |
Type |
Standard Type |
Import Country |
Direct Import from Japan |
Model No |
AM22PL-210M3W |
Mechanical Durability |
1,000,000 times or more |
Electrical Durability |
500,000 times or more (at AC220V 6A), 1 million times or more (at AC220V 3A) |
Contact Configuration |
1A |
Storage Temperature |
-40 to +80℃ |
Withstand Voltage |
Between charging part and ground / between opposite pole charging part: AC2000V 1 minute |
Short Circuit Protection Device |
Fuse 15A |
Return Function |
Manual |
Terminal Screw |
M3.5 plus/minus screw with square washer (self-lifting type) |
Frame |
Round frame |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Operation Mechanism |
Knob shape |
Number of Notches |
2 |
Insulation Resistance (MOhm) |
Between live part and ground / between different polarity live parts: 100 or more (at 500 VDC megger) |
Vibration Resistance |
Resonance test: Double amplitude 0.1 mm Frequency 10-55Hz / Constant vibration endurance test: Double amplitude 3.0 mm Frequency 16.7Hz |
Rated Insulation Voltage (V) |
AC/DC 250 |
Operation Ambient Temperature (°C) |
-10 to +50 (however, no freezing or condensation) |
Notch Angle |
90° |
Lamp Voltage (V) |
AC 220 |
