| Type of Product | Command Switch |
| Monotaro ID | 50027257 |
| Mounting Hole Diameter (Φmm) | 22.3 |
| Type | Standard Type |
Type of Product |
Command Switch |
Monotaro ID |
50027257 |
Mounting Hole Diameter (Φmm) |
22.3 |
Type |
Standard Type |
Protection Class |
IP65 (dust-proof, water-jet-proof): IEC 60529, IP65F (dust-proof, water-jet-proof, oil-proof): JIS C 0920 |
Import Country |
Direct Import from Japan |
Model No |
AM22WR-120B |
Mechanical Durability |
1,000,000 times or more |
Electrical Durability |
500,000 times or more (at AC220V 6A), 1 million times or more (at AC220V 3A) |
Contact Configuration |
2A |
Storage Temperature |
-40 to 80℃ |
Withstand Voltage |
Between live part and ground / between different polarity live parts: 2500 VAC for 1 minute |
Return Function |
Automatic (left → middle ← right) |
Terminal Screw |
M3.5 plus/minus screw with square washer (self-lifting type) |
Frame |
Round frame |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Number of Notches |
3 |
Mass (g) |
44 |
Insulation Resistance (MOhm) |
Between live part and ground / between different polarity live parts: 100 or more (at 500 VDC megger) |
Rated Insulation Voltage (V) |
AC/DC 600 |
Operation Ambient Temperature (°C) |
-10 to 70 (no freezing or condensation) |
Rated Frequency (Hz) |
50/60 |
Standard |
UL, CSA, EN standards (TUV), CE, CCC |
Notch Angle |
90° |
