| Type of Product | Command Switch |
| Monotaro ID | 50018586 |
| Mounting Hole Diameter (Φmm) | 25.5 |
| Type | Non-Illuminated Type |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Command Switch |
Monotaro ID |
50018586 |
Mounting Hole Diameter (Φmm) |
25.5 |
Type |
Non-Illuminated Type |
Protection Class |
IP65F |
Terminal Shape |
Screw terminal |
Button Shape |
Round (full guard type) |
Import Country |
Direct Import from Japan |
Model No |
AH25-G1B11 |
Operation Type |
Momentary |
Mechanical Durability |
5 million times or more |
Button Color |
Black |
Operating Frequency |
1800 Operation/Hour (40% usage rate) |
Relative Humidity |
45 to 85 % RH (-5 to 40°C) (no freezing or condensation) |
Electrical Durability |
500,000 times or more (at AC220V 6A), 1 million times or more (at AC220V 3A) |
Contact Configuration |
1A1B |
Withstand Voltage |
Between charging part and ground / between opposite pole charging part: AC2500V 1 minute |
Terminal Screw |
M3.5 plus/minus screw with square washer (self-lifting type) |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Withstand voltage (V / min) |
Between live parts and earth/between live parts of different polarity: AC 2500 |
Insulation Resistance (MOhm) |
over 100 |
Vibration Resistance |
Resonance test: Double amplitude 0.1 mm, frequency 10-55Hz Constant vibration endurance test: Double amplitude 3.0 mm, frequency 16.7Hz |
Open thermal current (A) |
10 |
Rated Insulation Voltage (V) |
AC/DC 600 |
Operation Ambient Temperature (°C) |
(Inside the panel) -20 to 70 (no freezing or condensation) |
