Ships within 25 days
View
View
View
View
| Type of Product | Command Switch |
| Monotaro ID | 64025789 |
| Type | Illuminated Push Button |
| Protection Class | Operation section: IP65 (oil-proof type) |
Type of Product |
Command Switch |
Monotaro ID |
64025789 |
Type |
Illuminated Push Button |
Protection Class |
Operation section: IP65 (oil-proof type) |
Terminal Shape |
For solder and tab (# 110) |
Import Country |
Direct Import from Japan |
Model No |
AR16E0L-C1B3R-CCC |
Mechanical Durability |
1,000,000 times or more |
Button Color |
Red |
Electrical Durability |
100,000 times or more (at AC220V 0.7A) |
Contact Configuration |
1C |
Storage Temperature |
-40 to 70℃ |
Withstand Voltage |
Between charging part and ground: AC2000V 1 minute, between different pole charging parts: AC2000V 1 minute (lamp terminal vs. contact terminal) |
Short Circuit Protection Device |
gG 2A (IEC60269 fuse) |
Return Function |
Momentary |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Light Colour |
Red |
Insulation Resistance (MOhm) |
100 or more (at 500 VDC megger) |
Rated Insulation Voltage (V) |
AC/DC 250 |
Operation Ambient Temperature (°C) |
-10 to 55 (no freezing or condensation) |
Lamp Type |
LED |
Lamp Voltage (V) |
AC/DC 12 |
Method |
All voltage type |
Voltage |
AC/DC 12 V |
