| Type of Product | Command Switch |
| Monotaro ID | 64006609 |
| Mounting Hole Diameter (Φmm) | 16.2 |
| Type | Push Button |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Command Switch |
Monotaro ID |
64006609 |
Mounting Hole Diameter (Φmm) |
16.2 |
Type |
Push Button |
Protection Class |
Operation unit (display unit) protection structure: IP65 (dust-resistant / jet-proof) IEC 60529, IP65F (dust-resistant / jet-proof / oil-proof) JIS C 0920 / IP2X (fast-connecting socket AR6S690, for connectors) When socket AR6S691-C or charging part protective cover AR6Y261 is installed) |
Terminal Shape |
For solder and tab (# 110) |
Import Country |
Direct Import from Japan |
Model No |
AR16F0T-C2W-CCC |
Mechanical Durability |
1,000,000 times or more |
Button Color |
Milky white |
Electrical Durability |
100,000 times or more (at AC220V 0.7A) |
Contact Configuration |
2C |
Storage Temperature |
-40 to 70℃ |
Withstand Voltage |
Between charging part and ground: AC2000V 1 minute, between opposite pole charging part: AC2000V 1 minute |
Short Circuit Protection Device |
gG 2A (IEC60269 fuse) |
Return Function |
Momentary |
Pollution Degree (Environment to Use) |
3 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Operation Mechanism |
Long angle flat type |
Insulation Resistance (MOhm) |
100 or more (at 500 VDC megger) |
Vibration Resistance |
Resonance test: Double amplitude 0.1 mm Frequency 10-55Hz / Constant vibration endurance test: Double amplitude 3.0 mm Frequency 16.7Hz |
Rated Insulation Voltage (V) |
AC/DC 250 |
Operation Ambient Temperature (°C) |
-10 to 55 (no freezing or condensation) |
Rated Impulse Withstand Voltage (kV) |
2.5 |
