| Type of Product | Command Switch |
| Monotaro ID | 50054663 |
| Mounting Hole Diameter (Φmm) | 22 |
| Type | Control Type |
Type of Product |
Command Switch |
Monotaro ID |
50054663 |
Mounting Hole Diameter (Φmm) |
22 |
Type |
Control Type |
Protection Class |
IP65 (oil-proof type) |
Import Country |
Direct Import from Japan |
Model No |
AR22PCR-607FB |
Mechanical Durability |
200,000 times or more |
Electrical Durability |
500,000 times or more (at AC220V 6A), 1 million times or more (at AC220V 3A) |
Contact Configuration |
1A1B |
Storage Temperature |
-40 to +80℃ |
Withstand Voltage |
Between charging part and ground / between opposite pole charging part: AC2500V 1 minute |
Short Circuit Protection Device |
Fuse 15A |
Return Function |
Mixing (left to middle) |
Terminal Screw |
M3.5 plus/minus screw with square washer (self-lifting type) |
Frame |
Round frame |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Number of Notches |
3 |
Insulation Resistance (MOhm) |
Between live part and ground / between different polarity live parts: 100 or more (at 500 VDC megger) |
Rated Insulation Voltage (V) |
AC/DC 600 |
Operation Ambient Temperature (°C) |
-20-+70 (no freezing or condensation) |
Notch Angle |
45° |
Rated Impulse Withstand Voltage (kV) |
6 |
