| Type of Product | Command Switch |
| Monotaro ID | 50033243 |
| Type | Non-Illuminated Type |
| Protection Class | IP65/IP65F |
Type of Product |
Command Switch |
Monotaro ID |
50033243 |
Type |
Non-Illuminated Type |
Protection Class |
IP65/IP65F |
Terminal Shape |
Solder terminal / tab terminal |
Button Shape |
Long angle (flat type) |
Import Country |
Direct Import from Japan |
Model No |
AR16F0T-C1B |
Operation Type |
Momentary |
Mechanical Durability |
1,000,000 times or more |
Conditional Short-Circuit Current |
1000 Amp |
Button Color |
Black |
Relative Humidity |
45 to 85% RH (at -5 to 40°C) (no freezing or condensation) |
Electrical Durability |
More than 100,000 times at AC220V 0.7A |
Contact Configuration |
1C |
Storage Temperature |
-40 to 70℃ |
Short Circuit Protection Device |
gG 2A (IEC60269 fuse) |
Pollution Degree (Environment to Use) |
3 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Name |
Push-button switch |
Insulation Resistance (MOhm) |
100 or more (with DC 500V mega) |
Operation Ambient Temperature (°C) |
-10 to 55 (no freezing or condensation) |
Standard |
UL, CSA, TUV, CCC |
Shock Resistance (m/s²) |
Malfunction: 100, Durability: 500 |
