| Type of Product | Flat Command Switch |
| Monotaro ID | 49980847 |
| Rated Voltage (V) | DC 5 to 24 |
| Type | Illuminated |
Type of Product |
Flat Command Switch |
Monotaro ID |
49980847 |
Rated Voltage (V) |
DC 5 to 24 |
Type |
Illuminated |
Terminal Shape |
Printed circuit board terminal |
Button Shape |
Square (projection) |
Structure |
Long life type |
Import Country |
Direct Import from Japan |
Model No |
AB12-SELG131-12 |
Button Color |
Green |
Relative Humidity |
45-85 % RH (However, no freezing or condensation) |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
button size (mm) |
□12 |
Illuminated Colors |
Yellow |
Name |
Closed end type |
Mass (g) |
2.0499999999999998 |
Withstand voltage (V / min) |
AC 500 |
Insulation Resistance (MOhm) |
100 or more (with DC 500V mega) |
Vibration Resistance |
Malfunction: 10-55Hz, double amplitude 1.5 mm |
Rated Insulation Voltage (V) |
DC 30 |
Operation Ambient Temperature (°C) |
-25 to 40 (no freezing or condensation) |
Durability |
10 million times or more |
Rated Current (mA) |
1 to 50 (resistive load) |
