Ships within 25 days
View
View
View
View
| Type | With Wiring/Wall-Mounted Type |
| Monotaro ID | 60008252 |
| Type of Product | EC1A control box (explosion-proof structure) 4-point 1-row type |
| Model No | EC1A-4103H6W2 |
Type |
With Wiring/Wall-Mounted Type |
Monotaro ID |
60008252 |
Type of Product |
EC1A control box (explosion-proof structure) 4-point 1-row type |
Model No |
EC1A-4103H6W2 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Paint Color |
5Y7/1 (semi-gloss) melamine resin baked coating, external surface only painted (paint film thickness: 20μm) [Pilot light lamp cover, meter frame and buzzer cap N1.5 (semi-gloss) melamine resin baked coating] |
Mounting Unit |
AC220V, lens color (red) / AC220V, lens color (green) / flat type, momentary, 1a-1b contacts, with nameplate <ON> / flat type, momentary, 1a-1b contacts, with nameplate <OFF> |
Protection Class |
IP65(IEC 60529) |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Insulation_Resistance (MΩ) |
5 or more (at DC500V megger) |
Rated Insulation Voltage (V) |
500 V |
Mass (g) |
About 5800 |
Symbol |
Pilot light (PL)/Push button switch (PB) |
Withstand voltage (V / min) |
AC2000 (live part - non-live part) |
