| Type | Wall-Mounted Type, For 4 Points |
| Monotaro ID | 48015575 |
| Type of Product | KGN type control box |
| Model No | KGN4102NYG |
Type |
Wall-Mounted Type, For 4 Points |
Monotaro ID |
48015575 |
Type of Product |
KGN type control box |
Model No |
KGN4102NYG |
Color |
Green (Unit) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Paint Color |
5Y7, 1 semi-gloss (melamine resin coating) |
Mounting Unit |
IDEC Φ30 series control unit |
Protection Class |
IP40(IEC 60529) |
Cable Entry Hole |
Double knockout processing, box top: Φ22・Φ27, box bottom: Φ16・Φ20 |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Insulation_Resistance (MΩ) |
5 or more |
Rated Carrying Current (A) |
10A |
Operation Ambient Temperature (°C) |
-25-50°C (No Icing) |
Rated Insulation Voltage (V) |
600 V |
Wall Thickness (mm) |
1 |
Box Material |
Steel plate |
Nameplate Display Characters |
No nameplate, ON, OFF, HAND-AUTO |
Unit Identification Number |
APN126DNR, ABN111, ABN111R, ASN211N |
Symbol |
Push button switch (PL/PB/SS/SS) |
Relative Humidity (% RH) |
45 to 85 (no condensation) |
Withstand voltage (V / min) |
AC2500 (between charged and non-charged parts) |
