Ships within 25 days
View
View
View
View
| Type | For 3 points |
| Monotaro ID | 6915011 |
| Type of Product | Kgnw Type Control Box |
| Model No | KGNW313Y |
Type |
For 3 points |
Monotaro ID |
6915011 |
Type of Product |
Kgnw Type Control Box |
Model No |
KGNW313Y |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Paint Color |
5Y7/1 Half gloss |
Protection Class |
IP40(IEC 60529・JEM1030) |
Relative Humidity |
45~85% (non-condensing) |
Cable Entry Hole |
Double knockout box top/Φ22, Φ27 <br> Box bottom/Φ16, Φ20 |
Withstand Voltage |
2500 VAC for 1 minute (between charged and uncharged parts) |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Number of Holes |
3 points |
Unit Mounting Hole |
Included |
Insulation_Resistance (MΩ) |
5 or more |
Operation Ambient Temperature (°C) |
-25~50 (no freezing) |
Diameter of Unit Mounting Hole (Φmm) |
22.2 (with counterbore) (3 locations) |
Rated Insulation Voltage (V) |
600 |
Mass (Kg) |
About 0.6 |
Dimension L (mm) |
200 |
Hole Diameter (Φmm) |
22.2 |
Box Material |
Steel plate |
