Ships within 25 days
View
View
View
View
| Type | Wall-Mounted Type, For 2 Points |
| Monotaro ID | 48015469 |
| Type of Product | KGN type control box |
| Model No | KGN2117NYB |
Type |
Wall-Mounted Type, For 2 Points |
Monotaro ID |
48015469 |
Type of Product |
KGN type control box |
Model No |
KGN2117NYB |
Color |
Black (Unit) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Paint Color |
5Y7, 1 semi-gloss (melamine resin coating) |
Mounting Unit |
IDEC Φ30 series control unit |
Protection Class |
IP40(IEC 60529) |
Cable Entry Hole |
Double knockout processing, box top: Φ22・Φ27, box bottom: Φ16・Φ20 |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Insulation_Resistance (MΩ) |
5 or more |
Rated Carrying Current (A) |
10A |
Operation Ambient Temperature (°C) |
-10 To 40°C (But Do Not Freeze) |
Rated Insulation Voltage (V) |
250 V |
Wall Thickness (mm) |
1 |
Box Material |
Steel plate |
Nameplate Display Characters |
No nameplate, no nameplate |
Unit Identification Number |
AZ12N, ABN111 |
Symbol |
Push button switch (BZ/PB) |
Relative Humidity (% RH) |
45 to 85 (no condensation) |
Withstand voltage (V / min) |
AC2000 (between live parts and non-live parts) |
