| Type of Product | Mini Control Relay |
| Model No | HH52SW AC200V |
| Country of Origin | Japan |
| Type | Standard Type |
Type of Product |
Mini Control Relay |
Model No |
HH52SW AC200V |
Country of Origin |
Japan |
Type |
Standard Type |
Standard |
c-UL, TUV |
Contact Configuration |
2C |
Insulation Resistance |
100 mΩ or more (with DC 500 V mega) |
Monotaro ID |
50206265 |
Terminal Shape |
Case front mounting |
Rated Voltage (V) |
AC 200 |
CR Circuit |
None |
Function |
Standard goods |
With or Without Diode |
None |
Operating Temperature Range |
-55 to 70℃ (no freezing or condensation) |
No. of Pole |
2 Pole |
Mass (g) |
About 31 |
Contact Resistance |
50 mΩ or less (initial value) |
Import Country |
Direct Import from Japan |
Frequency (Hz) |
50/60 |
Rated Insulation Voltage (V) |
250 |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Power Consumption |
50Hz: Approx. 1.2/1.4VA, 60Hz: Approx. 1/1.2 VA |
Protection Class |
In a case |
Type of Sign |
Case front mounting |
Outer Dimensions, Width W x Height H x Depth D (mm) |
21x27.8x40.6 mm |
