| Type of Product | Automatic Power Factor Controller Relay |
| Model No | APFC-414-4R |
| Frequency | 50/60 Hz |
| Country of Origin | India |
Type of Product |
Automatic Power Factor Controller Relay |
Model No |
APFC-414-4R |
Frequency |
50/60 Hz |
Country of Origin |
India |
Input Voltage |
40-300 V AC (L-N) |
Type |
With 1 CT |
Voltage |
90-550 V AC |
Size |
96X96 mm |
Phase |
3 Phase |
Name of Manufacturer/Packer/Importer |
NIPPEN ELECTRICAL INSTRUMENTS COMPANY |
Humidity |
0% to 95% |
Power Consumption |
7 VA Max |
Mounting Type |
Panel Mounting |
Accuracy |
±1% |
Frequency Range |
45 to 65 Hz |
Auxiliary Supply Voltage |
80-270 V AC/DC |
Display Type |
1 Row 4 Digit LED Display |
CT Primary |
5-5000 A AC |
Panel Cutout |
91x91 mm |
Input Current |
Nominal 5 A/AC (Min 50 mA, Max 6 A) |
Screw Tightening Torque (Nm) |
0.5 NM |
Stage |
4 |
Operating Temperature |
0 to 60°C |
Storage Temperature |
-20° to 60°C |
