| Type | For overload detection |
| Model No | SAO-QS6N |
| Type of Product | Current Sensor |
| Mass (g) | About 170 |
Type |
For overload detection |
Model No |
SAO-QS6N |
Type of Product |
Current Sensor |
Mass (g) |
About 170 |
Allowable Fluctuation of Voltage |
(Control power circuit) + 10%, -15% of rated voltage |
Influence of Voltage |
[Control voltage] Operating value: ±3% (at +10% and -15% change of rated voltage), Operating time (startup lock time): ±5% (at +10% and -15% change in rated voltage) |
Withstand Voltage |
Between all electrical circuits and mounting panel: AC2000V 1min, Between contact circuit and other circuits: AC2000V 1min, Contact gap: AC1000V 1min |
Operating Patterns |
Start-up lock and instantaneous operation characteristics |
Operating Humidity Range |
35 to 85%Rh |
Case Color |
Munsell 5Y7/1 |
Frequency (Hz) |
Rated frequency: 50/60, allowable fluctuation range: ±5% of rated frequency |
Overload Withstand |
(Motor circuit) 20 times the current setting value, 2 seconds, 2 times (1 minute interval) [Primary current of SET-3□ current converter], Continuous current: 125% of the maximum setting current value of each current setting range, (Control power supply circuit) AC power supply: 1.15 times the rated voltage, 3 hours, 1 time, DC power supply: 1.3 times the rated voltage, 3 hours, 1 time |
Monotaro ID |
46602245 |
Rated Current (A) |
(Motor circuit) 1-80 or 64-160 (three-phase) [Type SET-3 □ Current converter primary current] |
Import Country |
Direct Import from Japan |
Operating Temperature Range |
10 to 60℃ (but do not freeze) |
Power Consumption |
About 0.5 W |
Contact Configuration |
1C |
Storage Temperature |
-25 to 65℃ |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Remark |
Confirm Delivery Date Each Time |
Insulation Resistance (MOhm) |
Between all electrical circuits and mounting panel: 10 or more Between contact circuits and other circuits and between contact poles: 5 or more |
Specifications |
Operation with test button: Instant operation (operation display LED does not light) |
Rated Voltage (V) |
(Motor circuit) AC500 or less (three-phase) [Set-3□ Current converter primary voltage] |
