| Type of Product | Magnetic Proximity Sensor |
| Model No | AHM029 |
| Mounting | AHM029: M12 nut tightening torque 12 Nm, AHM030: M14 nut tightening torque 18 Nm |
| Output | NPN open collector (ON when close) |
Type of Product |
Magnetic Proximity Sensor |
Model No |
AHM029 |
Mounting |
AHM029: M12 nut tightening torque 12 Nm, AHM030: M14 nut tightening torque 18 Nm |
Output |
NPN open collector (ON when close) |
Case Material |
SUS303 |
Response Time |
16 μsec or less |
Protection Class |
IP67 |
Insulation Resistance |
DC250V (20M or more with mega, between the case) |
Specifications |
Detection magnetic pole: S pole/N pole, Magnetic sensitivity: 0.8mT±0.1mT, Magnetic detection orientation: Front |
Monotaro ID |
44719090 |
Withstand Voltage |
1000 VAC (1 minute, part of charging part, between cases) |
Current Consumption (mA) |
12.5 MAX |
Indicator Lamp |
S pole: red, N pole: green |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
ASA ELECTRONICS INDUSTRY |
Power Supply Voltage (V) |
DC 5 to 24 |
Operation Ambient Temperature (°C) |
-20 to +85 (no condensation) |
Cable |
4-core Φ3.1x1000mm black |
Output Current (mA) |
20 max |
Detection Area |
Magnetic metal |
Operating Ambient Humidity (% RH) |
20 to 95 |
