| Type of Product | Proximity Sensor |
| Model No | AR101 |
| Type | 3-wire type |
| Mounting | M2.5 |
Type of Product |
Proximity Sensor |
Model No |
AR101 |
Type |
3-wire type |
Mounting |
M2.5 |
Case Material |
[Main body] Heat-resistant ABS [Detector] SUS304 |
Specifications |
[Magnetic detection direction] Side |
Monotaro ID |
18303489 |
Detection Distance (mm) |
[Maximum] Iron wire Φ1: 1.0, high-speed steel drill Φ1.5: 1.5, iron □10x1t: 1.0 |
Indicator Lamp |
Red |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
ASA ELECTRONICS INDUSTRY |
Power Supply Voltage (V) |
DC 5 to 24 |
Cable |
3-core Φ2.8x1000mm Gray |
Output Current (mA) |
Up to 15 |
Detection Area |
Only magnetic materials such as iron |
Output Specifications |
NPN open collector (ON when close) |
