| Type of Product | Proximity Sensor |
| Model No | AR012B |
| Type | 3-wire type |
| Mounting | M12 nut |
Type of Product |
Proximity Sensor |
Model No |
AR012B |
Type |
3-wire type |
Mounting |
M12 nut |
Case Material |
SUS304 |
Specifications |
[Magnetic detection direction] Front |
Monotaro ID |
18303455 |
Detection Distance (mm) |
[Maximum] Iron □50xt10:6, Iron plate t0.1x10:5, Iron plate t0.05x10:4, Iron plate t0.03x10:2, High-speed steel drill Φ2:3 |
Indicator Lamp |
Red |
Country of Origin |
Japan |
Response Speed |
30msec |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
ASA ELECTRONICS INDUSTRY |
Power Supply Voltage (V) |
DC 5 to 24 |
Cable |
3-core Φ2.8x1000mm Black |
Output Current (mA) |
Up to 15 |
Detection Area |
Only magnetic materials such as iron |
Output Specifications |
NPN open collector (OFF when close) |
