| Type of Product | Magnetic Proximity Sensor |
| Model No | AH014H |
| Material | (Case nut) GF reinforced PBT: Black |
| Mounting | M2 Tightening torque 0.15 Nm or less |
Type of Product |
Magnetic Proximity Sensor |
Model No |
AH014H |
Material |
(Case nut) GF reinforced PBT: Black |
Mounting |
M2 Tightening torque 0.15 Nm or less |
Protection Class |
IP65 |
Specifications |
Detection magnetic pole: S pole, magnetic sensitivity: 3-4mT |
Monotaro ID |
22206686 |
Sensor Shape |
Square |
Head Shape |
Square |
Current Consumption (mA) |
4MAX |
Indicator Lamp |
Red |
Country of Origin |
Japan |
Response Speed |
16 μsec or less |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
ASA ELECTRONICS INDUSTRY |
Output Current (mA) |
15MAX |
Output Specifications |
NPN (ON when close) |
