| Type of Product | Proximity Sensor |
| Model No | FL7M-10T7D |
| Cable Length (m) | (Standard) 2 |
| Material | (Sensor) Case: Brass Ni Plating, (Sensing Surface) Pbt Resin (Connector) Holder: Pbt Resin |
Type of Product |
Proximity Sensor |
Model No |
FL7M-10T7D |
Cable Length (m) |
(Standard) 2 |
Material |
(Sensor) Case: Brass Ni Plating, (Sensing Surface) Pbt Resin (Connector) Holder: Pbt Resin |
Operating Temperature Range |
-10 to +60℃ |
Protection Class |
IP67 (IEC standard), IP67G (JEM standard) |
Control Output |
(Switching Current) 5 to 100 Ma (Residual Voltage) When Using Ac Power Supply: 10 V Or Less (5 Ma Load Current, 2 M Cord Length), When Using Dc: 6 V Or Less (100 Ma Load Current, 2 M Cord Length) |
Connection Type |
Pre-Wire (Standard Cord Length 2M) |
Protection Circuit |
Surge Absorption, Load Short-Circuit Protection (However, At 20 to 40 Vdc) |
Power Supply Voltage |
AC 100/200 V 50/60Hz DC24 V |
Response Frequency (Hz) |
When Using Ac Power: 25, When Using Dc Power: 400 |
Monotaro ID |
38438784 |
Withstand Voltage |
AC4000V 50 / 60Hz for 1 minute: Between live parts and case |
Setting Distance (mm) |
0 to 8 |
Head Shape |
Screw |
Operating Voltage Range (V) |
AC48 to 240V(AC40 to 250V), DC24 to 240V(DC20 to 250V) |
Detection Distance (mm) |
10±1 |
Leakage Current (mA) |
When Using Ac Power: 2 Ma Or Less, When Using Dc Power: 1 Ma Or Less |
Mass (g) |
Approx. 270 (Body) |
Outer Diameter |
M30 |
Country of Origin |
Japan |
Detection Method |
High Frequency Oscillation Type |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Azbil Corporation |
Shock Resistance (m/s²) |
980 X, Y, Z Directions 10 Times |
Insulation Resistance (MOhm) |
50 or More (At 500 V DC) |
