| Type of Product | Proximity Switch |
| Model No | FL7M-3J6HDG-L5 |
| Type | Polar |
| Cable Length (m) | 10 |
Type of Product |
Proximity Switch |
Model No |
FL7M-3J6HDG-L5 |
Type |
Polar |
Cable Length (m) |
10 |
Material |
Contact: Gold-Plated Brass |
Case Material |
Sensor: Nickel-Plated Brass |
Operating Temperature Range |
-25 to 70℃ |
Protection Class |
IP67 (IEC standard), IP67G (JEM standard) |
Control Output |
(Switching Current) 3 to 100 mA Or Less, (Residual Voltage) 3V Or Less (Switching Current 100 mA, When Cord Length Is 2M), (Output Withstand Voltage) Dc30V |
Connection Type |
Pre-Wired Connector |
Housing Material |
Connector: Polyester Elastomer |
Specifications |
Cylinder Type Dc 2-Wire, Long Body Type |
Monotaro ID |
7775985 |
Withstand Voltage |
AC2500V 50/60Hz 1 minute: Between live parts and case |
Head Shape |
Screw |
Standard Sensing Object (mm) |
12x12, T = 1, Iron |
Country of Origin |
Japan |
Detection Method |
High Frequency Oscillation Type |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Azbil Corporation |
Power Supply Voltage (V) |
DC 12/24 |
Insulation Resistance (MOhm) |
50 Or More (Dc500V) |
