| Type of Product | Proximity Sensor Ultra Compact Type E2S (Dc 3-Wire Type) |
| Model No | E2S-W13B 1M |
| Type | Square, Non-Shielded, Different Frequency Type |
| Cable Length (m) | 1 |
Type of Product |
Proximity Sensor Ultra Compact Type E2S (Dc 3-Wire Type) |
Model No |
E2S-W13B 1M |
Type |
Square, Non-Shielded, Different Frequency Type |
Cable Length (m) |
1 |
Output |
DC 3-wire NPN |
Case Material |
Polyarylate |
Protection Class |
IEC standard IP67 |
Shape |
Unshielded |
Control Output |
Switching capacity: NPN open collector output 50 mA or less (30 VDC or less), residual voltage: 1 V or less (load current 50 mA and cord length 1 m) |
Connection Type |
Cord Drawer Type |
Detection Distance |
1.6 mm ±15% |
Power Supply Voltage |
DC12 to 24V ????(p-p)10%?? |
Monotaro ID |
39047696 |
Sensor Shape |
Rectangular |
Withstand Voltage |
Between terminals of the same polarity: AC1000 (50/60Hz), between live metal parts and earth, between each terminal and non-live metal parts, between terminals of different polarities: AC1500 (50/60Hz) |
Head Shape |
Corner |
Standard Sensing Object (mm) |
Iron 12x12x1 |
Detection Distance (mm) |
1.6±15% |
Current Consumption (mA) |
13 or less (24 VDC, no load) |
Mass (g) |
Approximately 10 (packed) |
Country of Origin |
China |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Included Components |
Mounting bracket |
Category |
Cylindrical Proximity Sensor |
