| Type of Product | Proximity Sensor Flat Type |
| Model No | TL-W5MC2 2M |
| Type | Rectangular, Unshielded Type |
| Cable Length (m) | 2 |
Type of Product |
Proximity Sensor Flat Type |
Model No |
TL-W5MC2 2M |
Type |
Rectangular, Unshielded Type |
Cable Length (m) |
2 |
Output |
DC 3-wire NPN |
Case Material |
Heat resistant ABS |
Protection Class |
IEC standard IP67 |
Shape |
Unshielded type |
Control Output |
Switching capacity: NPN open collector 50 mA or less at 12 VDC (30 VDC or less), 100 mA or less at 24 VDC (30 VDC or less), residual voltage: 1 V or less (when load current is 50 mA and cord length is 2 m) |
Connection Type |
Cord Drawer Type |
Detection Distance |
5 mm ±10% |
Series |
TL-W Series |
Insulation Resistance |
50 or more (at 500 VDC) between live parts and case |
Power Supply Voltage |
DC12-24 Ripple (pp) 10% or less |
Monotaro ID |
39098315 |
Withstand Voltage |
AC1000 50/60Hz 1min Between live parts and case |
Standard Sensing Object (mm) |
Iron 18x18x1 |
Detection Distance (mm) |
5±10% |
Current Consumption (mA) |
10 or less (at DC24V, no load) |
Mass (g) |
Approx. 80 (packed) |
Country of Origin |
China |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Included Components |
Instruction manual |
Category |
Cylindrical Proximity Sensor |
