| Type of Product | Resin Case Type Proximity Sensor |
| Model No | E2F-X2Y25-2M |
| Type | Column type |
| Cable Length (m) | 2 |
Type of Product |
Resin Case Type Proximity Sensor |
Model No |
E2F-X2Y25-2M |
Type |
Column type |
Cable Length (m) |
2 |
Case Material |
Polyarylate |
Protection Class |
IEC standard IP68 |
Connection Type |
Cord drawer type |
Power Supply Voltage |
AC 24 to 240 V |
Specifications |
Different frequency type |
Monotaro ID |
46512891 |
Setting Distance (mm) |
0 to 1.6 |
Head Shape |
screw |
Standard Sensing Object (mm) |
Iron 12 x 12 x 1 |
Influence of Voltage |
± 1% or less of sensing distance at rated power supply voltage within the range of rated power supply voltage ± 10% |
Detection Distance (mm) |
2±10% |
Ambient Humidity (% RH) |
Operating and storage: 35 to 95 each (no condensation) |
Mass (g) |
Approx. 50 (packed) |
Country of Origin |
CHINA |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Included Components |
Instruction manual |
Insulation Resistance (MOhm) |
Between live parts and case: 50 or more (at 500 V DC) |
Operation Ambient Temperature (°C) |
During operation and storage: -25 to 70 (but do not allow freezing or condensation) |
Locator Material |
Possible: Magnetic metal (non-magnetic metal reduces the detection distance.) |
