| Type of Product | Proximity Sensor |
| Model No | E2EW-X2D112 2M |
| Type | Cylindrical type (with screw), high frequency oscillation, shielded type |
| Cable Length (m) | 2 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Proximity Sensor |
Model No |
E2EW-X2D112 2M |
Type |
Cylindrical type (with screw), high frequency oscillation, shielded type |
Cable Length (m) |
2 |
Material |
Fastening nut: Stainless steel (SUS303), Cord: Polyvinyl chloride (PVC) |
Case Material |
Stainless steel (SUS303) |
Protection Class |
IEC60529 standard IP67 |
Connection Type |
Cord drawer type |
Protection Circuit |
Surge absorption, load short-circuit protection |
Power Supply Voltage |
DC10 to 30, including ripple (pp) 10%, Class 2 |
Monotaro ID |
50591627 |
Setting Distance (mm) |
0 to 1.4 |
Head Shape |
Column type |
Standard Sensing Object (mm) |
Iron 12x12x1 |
Detection Distance (mm) |
2±10% |
Cord |
PVC cord |
Mass (g) |
Approx. 140 (packed) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Pack of |
1 Pcs |
Included Components |
Instruction manual, tightening nut, washer with teeth |
Conform to |
IO-Link: Not supported |
Insulation Resistance (MOhm) |
Between li Ve parts and case: 50 mohm or more (at 500 V DC) |
Operation Ambient Temperature (°C) |
Operating: 0 to 85, Storage: -15 to 85 (but do not freeze or condense) |
Thickness (mm) |
(detection surface) 0.8 |
