| Type of Product | Long Distance Proximity Sensor |
| Model No | TL-LP50B-1M |
| Type | Column type |
| Cable Length (m) | 1 |
Type of Product |
Long Distance Proximity Sensor |
Model No |
TL-LP50B-1M |
Type |
Column type |
Cable Length (m) |
1 |
Case Material |
Aluminum die casting |
Protection Class |
IEC standard IP67 |
Connection Type |
Pre-wired model |
Power Supply Voltage |
DC 12 to 24 V Ripple (pp) 10% or less |
Specifications |
Different frequency |
Monotaro ID |
46554471 |
Setting Distance (mm) |
0 to 40 |
Standard Sensing Object (mm) |
Iron 100 x 100 x 1 |
Influence of Voltage |
± 2% or less of sensing distance at rated power supply voltage within the range of rated power supply voltage ± 10% |
Operating Voltage Range (V) |
DC 10 to 30 |
Detection Distance (mm) |
50±10% |
Current Consumption (mA) |
10 or less (no load) |
Mass (g) |
About 1.4 |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Insulation Resistance (MOhm) |
Between live parts and case: 50 or more (at 500 V DC) |
Operation Ambient Temperature (°C) |
During operation and storage: -25 to 70 (but do not allow freezing or condensation) |
Influence of Temperature |
Within the temperature range of -25 to 70°C, detection distance at 23°C is within ±10% |
Locator Material |
Magnetic metal (Non-magnetic metal decreases the detection distance.) |
