| Type of Product | Small Diameter Type Proximity Sensor |
| Model No | E2E-C06S02-WC-B1-R2M |
| Type | Column type |
| Cable Length (m) | 2 |
Type of Product |
Small Diameter Type Proximity Sensor |
Model No |
E2E-C06S02-WC-B1-R2M |
Type |
Column type |
Cable Length (m) |
2 |
Output |
DC 3-wire PNP open collector output |
Case Material |
SUS303(EN1.4305) |
Protection Class |
IEC standard IP67 |
Connection Type |
PVC cord drawer type |
Protection Circuit |
Power supply reverse connection protection, surge absorption, load short circuit protection, output reverse connection protection |
Power Supply Voltage |
DC 10-30 V (including 10% ripple (pp)) |
Monotaro ID |
66466697 |
Setting Distance (mm) |
0 to 1.4 |
Head Shape |
Circle |
Standard Sensing Object (mm) |
Iron 6.5x6.5x1 |
Detection Distance (mm) |
2 |
Ambient Humidity (% RH) |
Operating and storage: 35 to 95 each (no condensation) |
Cord |
Robot (flexible) PVC cord |
Mass (g) |
Approx. 55 (packed) |
Country of Origin |
CHINA |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Included Components |
Instruction manual, model label, mounting bracket (sold separately) |
Case Type |
Cylindrical |
Insulation Resistance (MOhm) |
Between live parts and case: 50 or more (at 500 V DC) |
Operation Ambient Temperature (°C) |
During operation and storage: -25 to 70 (but do not allow freezing or condensation) |
