Ships within 19 days
Cable Length (m)
Model No
View
View
View
View
| Type of Product | Proximity Sensor Flat Type |
| Model No | TL-W20ME1 2M |
| Type | Rectangular, Unshielded Type |
| Cable Length (m) | 2 |
Type of Product |
Proximity Sensor Flat Type |
Model No |
TL-W20ME1 2M |
Type |
Rectangular, Unshielded Type |
Cable Length (m) |
2 |
Case Material |
Heat resistant ABS |
Protection Class |
IEC standard IP67 |
Shape |
Unshielded type |
Connection Type |
Cord drawer type |
Protection Circuit |
Reverse connection protection, surge absorption |
Series |
TL-W Series |
Power Supply Voltage |
DC12-24 Ripple (pp) 10% or less |
Monotaro ID |
8586286 |
Standard Sensing Object (mm) |
Iron 50x50x1 |
Detection Distance (mm) |
20±10% |
Current Consumption (mA) |
8(12V)、15(24V) |
Ambient Humidity (% RH) |
Operating and storage: 35 to 95 each (no condensation) |
Mass (g) |
Approx. 210 (packed) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Included Components |
Instruction manual |
Manufacturer Part Number |
TL-W20ME1 2M |
Insulation Resistance (MOhm) |
Between live parts and case: 50 or more (at 500 VDC) |
Operation Ambient Temperature (°C) |
During operation and storage: -25 to 70 (but do not allow freezing or condensation) (In an oil-resistant environment, use at an upper limit of 40.) |
