| Type of Product | Proximity Sensor |
| Model No | E2EW-QX5B318 5M |
| Type | Spatter-resistant coating, cylindrical type (with threads), high-frequency oscillation method, shielded type |
| Cable Length (m) | 5 |
Type of Product |
Proximity Sensor |
Model No |
E2EW-QX5B318 5M |
Type |
Spatter-resistant coating, cylindrical type (with threads), high-frequency oscillation method, shielded type |
Cable Length (m) |
5 |
Size |
M18 |
Material |
Fastening nut: Fluorine resin coating (base material: SUS303), cord: polyvinyl chloride (PVC) |
Case Material |
Fluorine resin coating (base material: SUS303) |
Protection Class |
IEC60529 standard IP67 |
Control Output |
PNP open collector |
Connection Type |
Cord drawer type |
Power Supply Voltage |
DC 10 to 30 V, including ripple (pp) 10%, Class 2 [operating voltage range] |
Specifications |
●Major IO-Link functions: NO/NC operation mode switching, self-diagnosis function enable/disable selection, excessive approach judgment distance selection, control output timer function and timer time selection, ON delay timer time selection for unstable output (IO-Link communication mode), monitor output, power-on time reading, sensor internal temperature reading, initial reset |
Monotaro ID |
58244017 |
Head Shape |
Column type |
Standard Sensing Object (mm) |
Iron 18x18x1 |
Detection Distance (mm) |
5±10% |
Current Consumption (mA) |
20 or less |
Cord |
PVC cord |
Mass (g) |
About 160 |
Country of Origin |
CHINA |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Included Components |
Instruction manual, tightening nut, washer with teeth |
Thickness (mm) |
Detection surface: 0.8 |
