Ships within 19 days
Detection Distance (mm)
Model No
View
View
View
View
| Type of Product | Proximity Sensor |
| Model No | E2EW-X22B3D30-M1TJ 0.3M |
| Type | Cylindrical type (with screw), pulse excitation method, shielded type |
| Cable Length (m) | 0.3 |
Type of Product |
Proximity Sensor |
Model No |
E2EW-X22B3D30-M1TJ 0.3M |
Type |
Cylindrical type (with screw), pulse excitation method, shielded type |
Cable Length (m) |
0.3 |
Size |
M30 |
Material |
Tightening nut: Stainless steel (SUS303), Cord: Polyvinyl chloride (PVC) |
Case Material |
Stainless steel (SUS303) |
Protection Class |
IEC60529 standard IP67 |
Control Output |
PNP open collector |
Connection Type |
M12 smart click connector relay type |
Power Supply Voltage |
DC 10 to 30 V, including ripple (pp) 10%, Class 2 |
Specifications |
●Major IO-Link functions: NO/NC operation mode switching, self-diagnosis function enable/disable selection, excessive approach judgment distance selection, control output timer function and timer time selection, ON delay timer time selection for unstable output (IO-Link communication mode), monitor output, power-on time reading, sensor internal temperature reading, initial reset |
Monotaro ID |
58245049 |
Head Shape |
Column type |
Standard Sensing Object (mm) |
Iron 66x66x1 |
Detection Distance (mm) |
22±10% |
Cord |
PVC cord |
Mass (g) |
About 160 |
Country of Origin |
China |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Included Components |
Instruction manual, tightening nut, washer with teeth |
Insulation Resistance (MOhm) |
Between live parts and case: 50 or more (at 500 V DC) |
Thickness (mm) |
Detection surface: 0.5 |
