| Type of Product | Micro Proximity Sensor |
| Model No | GX-H15B-P |
| Type | Built-in amplifier |
| Cable Length (m) | 1 |
Type of Product |
Micro Proximity Sensor |
Model No |
GX-H15B-P |
Type |
Built-in amplifier |
Cable Length (m) |
1 |
Material |
Indicator light: Polyester |
Output Type |
PNP Transistor open collector |
Protection Class |
IP68(IEC), IP68G |
Shock Resistance |
10000 m/s² (about 1000G) 3 times in each XYZ direction |
Monotaro ID |
47110226 |
Ambient Humidity to Use |
35-85% RH, (when stored) 35-95% RH |
Head Shape |
Square |
Standard Sensing Object (mm) |
Iron 20x20xt1 |
Current Consumption (mA) |
15 or less |
Mass (g) |
About 20 |
Country of Origin |
Japan |
Storage Temperature Range |
-40 to 85℃ |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Panasonic Devices SUNX Co., Ltd. |
Vibration Resistance (Destruction) |
10 to 500Hz, double amplitude 3mm (MAX.20G), 2 hours each in XYZ directions |
Power Supply Voltage (V) |
12 to 24 V DC 10/-15% Ripple P-P 10% or less |
Main Unit Material |
PBT |
Insulation Resistance (MOhm) |
50 Mohm or more at DC 500 V Mega |
Operation Ambient Temperature (°C) |
-25 to 70 |
Repeatability (mm) |
0.04 or less (detection axis direction, direction perpendicular to the detection axis) |
