| Type of Product | Cylindrical Roller Bearing |
| Model No | N207 |
| Material | High Carbon Chromium Bearing Steel |
| Chamfer Dimension r1 (mm) | 0.6 (minimum) |
Type of Product |
Cylindrical Roller Bearing |
Model No |
N207 |
Material |
High Carbon Chromium Bearing Steel |
Chamfer Dimension r1 (mm) |
0.6 (minimum) |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fujikoshi Corporation |
Race ring shape |
Cylindrical roller bearing |
Shield Shape |
Open type |
Import Country |
Direct Import from Japan |
Load direction |
Radial |
JIS grade |
0 |
Rolling element material |
High carbon chromium bearing steel |
Outer Diameter D (Φmm) |
72 |
Chamfer Dimension r (mm) |
1.1 (minimum) |
Monotaro ID |
68557316 |
Basic dynamic load rating Cr (N) |
33500 |
Width B (mm) |
17 |
Basic static load rating Cor (N) |
31500 |
No. of Track Trains |
Single row |
Inner Diameter d (Φmm) |
35 |
Outer ring type |
Flat |
Circumscribed Circle Diameter Ew (Φmm) |
61.8 |
Allowable Speed (min-1[r.p.m]) Grease Lubrication |
9500 |
Mass (g) |
290 g |
Allowable Speed (min-1 [r.p.m]) Oil Lubrication |
11000 |
Inscribed Circle Diameter Fw (Φmm) |
43.8 |
