| Type of Product | Cylindrical Roller Bearing |
| Model No | NJ210 |
| Material | High Carbon Chromium Bearing Steel |
| Chamfer Dimension r1 (mm) | 1.1 (minimum) |
Type of Product |
Cylindrical Roller Bearing |
Model No |
NJ210 |
Material |
High Carbon Chromium Bearing Steel |
Chamfer Dimension r1 (mm) |
1.1 (minimum) |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fujikoshi Corporation |
Race ring shape |
Cylindrical roller bearing |
Shield Shape |
Open type |
Import Country |
Direct Import from Japan |
Load direction |
Radial |
JIS grade |
0 |
Rolling element material |
High carbon chromium bearing steel |
Outer Diameter D (Φmm) |
90 |
Chamfer Dimension r (mm) |
1.1 (minimum) |
Monotaro ID |
68557596 |
Basic dynamic load rating Cr (N) |
48000 |
Width B (mm) |
20 |
Basic static load rating Cor (N) |
51000 |
No. of Track Trains |
Single row |
Inner Diameter d (Φmm) |
50 |
Outer ring type |
Flat |
Circumscribed Circle Diameter Ew (Φmm) |
80.400000000000006 |
Allowable Speed (min-1[r.p.m]) Grease Lubrication |
7100 |
Allowable Speed (min-1 [r.p.m]) Oil Lubrication |
8500 |
Inscribed Circle Diameter Fw (Φmm) |
60.4 |
