| Type of Product | Single Row Cylindrical Roller Bearing NU Type |
| Model No | NU218W |
| Material | High Carbon Chromium Bearing Steel |
| Chamfer Dimension r1 (mm) | 2 (minimum) |
Type of Product |
Single Row Cylindrical Roller Bearing NU Type |
Model No |
NU218W |
Material |
High Carbon Chromium Bearing Steel |
Chamfer Dimension r1 (mm) |
2 (minimum) |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
NSK Ltd. |
Race ring shape |
Cylindrical roller bearing |
Shield Shape |
Open type |
Import Country |
Direct Import from Japan |
Load direction |
Radial |
JIS grade |
0 |
Rolling element material |
High carbon chromium bearing steel |
Outer Diameter D (Φmm) |
160 |
Chamfer Dimension r (mm) |
2 (minimum) |
Monotaro ID |
7023667 |
Width B (mm) |
30 |
No. of Track Trains |
Single row |
Inner Diameter d (Φmm) |
90 |
Outer ring type |
Flat |
Mass (Kg) |
2.6 Kg |
Allowable Speed (min-1[r.p.m]) Grease Lubrication |
4000 |
Mass (g) |
2600 |
Allowable Speed (min-1 [r.p.m]) Oil Lubrication |
4800 |
Basic load rating Cor (N) |
217000 |
Basic load rating Cr (N) |
182000 |
Inscribed Circle Diameter Fw (Φmm) |
107 |
