| Type of Product | Cylindrical Roller Bearing |
| Model No | NJ2209ET2X |
| Material | High Carbon Chromium Bearing Steel |
| Country of Origin | Japan |
Type of Product |
Cylindrical Roller Bearing |
Model No |
NJ2209ET2X |
Material |
High Carbon Chromium Bearing Steel |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
NTN Corporation |
Race ring shape |
Cylindrical roller bearing |
Shield Shape |
Open type |
Import Country |
Direct Import from Japan |
Load direction |
Radial |
JIS grade |
0 |
Rolling element material |
High carbon chromium bearing steel |
Outer Diameter D (Φmm) |
85 |
Chamfer Dimension r (mm) |
1.1000000000000001 |
Monotaro ID |
40146732 |
Basic dynamic load rating Cr (N) |
76000 |
Width B (mm) |
23 |
Permissible Speed (min-1) Oil Lubrication |
8000 |
Basic static load rating Cor (N) |
84500 |
No. of Track Trains |
Single row |
Permissible Speed (min-1) Grease Lubrication |
6800 |
Inner Diameter d (Φmm) |
45 |
Outer ring type |
Flat |
Mass (g) |
532 g |
Trusco Part No. |
819-6857 |
