| Type of Product | Deep Groove Ball Bearing |
| Model No | 626ZZNR |
| Inner Diameter | 6 mm |
| Country of Origin | Japan |
Type of Product |
Deep Groove Ball Bearing |
Model No |
626ZZNR |
Inner Diameter |
6 mm |
Country of Origin |
Japan |
Load direction |
Radial |
Outer ring type |
With retaining ring |
No. of Track Trains |
Single row |
Shield Shape |
Double-sided steel plate shield type (snap ring fixed) |
Race ring shape |
Deep groove ball bearings |
Outer Diameter D (Φmm) |
19 |
Rolling element material |
SUJ2 or equivalent bearing steel |
JIS grade |
0 |
Basic static load rating Cor (N) |
1053 |
Width B (mm) |
6 |
Basic dynamic load rating Cr (N) |
2614 |
Monotaro ID |
38667045 |
Reference mass (g) |
8 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
MinebeaMitsumi Inc. |
Nominal No. |
(ISO/JIS)626ZZNR |
Chamfer Dimension rs (mm) |
0.3 |
Main Unit Material |
SUJ2 or equivalent bearing steel |
Dimensions L (mm) |
9.1999999999999993 |
Dimension Lo (mm) |
16.68 |
Retaining Ring Position C2 (mm) |
1.5 |
Ring Outer Diameter |
φ22.1 mm |
