| Type of Product | Deep Groove Ball Bearing |
| Model No | DDRF-1640 |
| Inner Diameter | 4 mm |
| Country of Origin | Japan |
Type of Product |
Deep Groove Ball Bearing |
Model No |
DDRF-1640 |
Inner Diameter |
4 mm |
Country of Origin |
Japan |
Load direction |
Radial |
Outer ring type |
With flange |
No. of Track Trains |
Single row |
Shield Shape |
Open type |
Race ring shape |
Deep groove ball bearings |
Outer Diameter D (Φmm) |
16 |
JIS grade |
0 |
Basic static load rating Cor (N) |
671 |
Width B (mm) |
5 |
Basic dynamic load rating Cr (N) |
1735 |
Monotaro ID |
38666363 |
Reference mass (g) |
5.29 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
MinebeaMitsumi Inc. |
Nominal No. |
(ISO/JIS)F634 |
Chamfer Dimension rs (mm) |
0.3 |
Main Unit Material |
Martensitic stainless steel |
Flange Width C1 (mm) |
1 |
Flange Outer Diameter FD (Φmm) |
18 |
Dimensions L (mm) |
7.8 |
Dimension Lo (mm) |
13.2 |
