| Type of Product | Deep Groove Ball Bearing |
| Model No | DDRFW-1560ZZ |
| Country of Origin | Japan |
| Load direction | Radial |
Type of Product |
Deep Groove Ball Bearing |
Model No |
DDRFW-1560ZZ |
Country of Origin |
Japan |
Load direction |
Radial |
Outer ring type |
With flange |
Inner Diameter d (Φmm) |
6 |
No. of Track Trains |
Single row |
Shield Shape |
Double-sided steel plate shield type (snap ring fixed) |
Race ring shape |
Deep groove ball bearings |
Outer Diameter D (Φmm) |
15 |
Rolling element material |
Martensitic stainless steel |
JIS grade |
0 |
Width B (mm) |
5 |
Monotaro ID |
38666503 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
MinebeaMitsumi Inc. |
Nominal No. |
(ISO/JIS)F696ZZ |
Main Unit Material |
Martensitic stainless steel |
Flange Width C1 (mm) |
1 |
Flange Outer Diameter FD (Φmm) |
17 |
Dimensions L (mm) |
7.8 |
Dimension Lo (mm) |
13.2 |
