Ships within 25 days
View
View
View
View
| Type of Product | Deep Groove Ball Bearing |
| Model No | RF-2280HH |
| Country of Origin | Japan |
| Load direction | Radial |
Type of Product |
Deep Groove Ball Bearing |
Model No |
RF-2280HH |
Country of Origin |
Japan |
Load direction |
Radial |
Outer ring type |
With flange |
Inner Diameter d (Φmm) |
8 |
No. of Track Trains |
Single row |
Shield Shape |
Double-sided steel plate shield type |
Race ring shape |
Deep groove ball bearings |
Outer Diameter D (Φmm) |
22 |
Rolling element material |
SUJ2 or equivalent bearing steel |
JIS grade |
0 |
Basic static load rating Cor (N) |
1368 |
Width B (mm) |
7 |
Basic dynamic load rating Cr (N) |
3297 |
Monotaro ID |
47121785 |
RoHS Directive |
Correspondence |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
MinebeaMitsumi Inc. |
Nominal No. |
(ISO/JIS)F608ZZ |
Chamfer Dimension rs (mm) |
0.5 |
Main Unit Material |
SUJ2 or equivalent bearing steel |
Flange Width C1 (mm) |
1.5 |
Flange Outer Diameter FD (Φmm) |
25 |
Dimensions L (mm) |
10.8 |
Dimension Lo (mm) |
19.07 |
