Ships within 19 days
View
View
View
View
| Type of Product | Radial Ball Bearing |
| Model No | LNR-1680HH |
| Country of Origin | Japan |
| Chamfer Dimension r1 (mm) | 0.2 |
Type of Product |
Radial Ball Bearing |
Model No |
LNR-1680HH |
Country of Origin |
Japan |
Chamfer Dimension r1 (mm) |
0.2 |
Load direction |
Radial |
Outer ring type |
With retaining ring |
Inner Diameter d (Φmm) |
8 |
No. of Track Trains |
Single row |
Shield Shape |
Double-sided steel plate shield type |
Race ring shape |
Deep groove ball bearings |
Outer Diameter D (Φmm) |
16 |
Rolling element material |
SUJ2 or equivalent bearing steel |
JIS grade |
0 |
Basic static load rating Cor (N) |
712 |
Width B (mm) |
5 |
Basic dynamic load rating Cr (N) |
1606 |
Monotaro ID |
36796602 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
MinebeaMitsumi Inc. |
Main Unit Material |
SUJ2 or equivalent bearing steel |
JIS Nominal Size |
688ZZNR |
Retaining Ring Position C2 (mm) |
0.95 |
Ring Outer Diameter |
φ18.2 mm |
Looking for bulk pricing or different specifications?
