| Type of Product | Single Row Radial Ball Bearing |
| Material | High Carbon Chrome Steel |
| Model No | TMB306 |
| Weight | 0.360 Kg |
Type of Product |
Single Row Radial Ball Bearing |
Material |
High Carbon Chrome Steel |
Model No |
TMB306 |
Weight |
0.360 Kg |
Series |
TMB3 |
Limiting Speed (Oil) |
12,000 RPM |
Limiting Speed (Grease) |
10,000 RPM |
Bearing Type |
Deep Groove Ball Bearing |
Bore Type |
Round |
Cage Type |
Pressed |
Width (B) |
19 mm |
Bore Diameter (d) |
30 mm |
Precision |
Not Specified |
Internal Clearance |
CN |
Country of Origin |
India |
Cage Material |
Steel |
Dynamic Load Rating |
26.70 kN |
Static Load Rating |
15.00 kN |
Ball Material |
Steel |
Seal Type |
Open |
Operating Temperature Range |
-40 ºC to 120 ºC |
Enclosure |
Open |
Name of Manufacturer/Packer/Importer |
Mechanical Solutions |
Outside Diameter (D) |
72 mm |
Snap Ring |
Without Snap Ring |
Corner Radius (r) |
1.1 mm |
Corner Radius (r1) |
0.5 mm |
Configuration |
Single Row |
